Côn giảm áp lực nối nhẫn

    (METRIC)

    TUBE O.D. CATALOG
    NUMBER    		 A C1 C2 D1 D2 E G1 G2 F H
    T1 T2
    4 6 RU-4-6 39.4 16.1 17.7 13.7 15.3 3 12 14 14 25.4
    6 8 RU-6-8 42.3 17.7 18.6 15.3 16.2 5 14 17 17 27.7
    6 10 RU-6-10 44.5 17.7 19.5 15.3 17.2 5 14 19 19 29.5
    6 12 RU-6-12 45.1 18.6 19.5 16.2 17.2 6 17 19 19 30.0
    8 10 RU-8-10 47 17.7 22.0 15.3 22.8 5 14 22 22 29.5
    8 12 RU-8-12 47.8 18.6 22.0 16.2 22.8 6 17 22 22 30.2
    10 12 RU-10-12 48.7 19.5 22.0 17.2 22.8 8 19 22 22 31.0
    12 16 RU-12-16 52.0 22.0 22.0 22.8 24.4 10 22 25 25 31.8
    18 25 RU-18-25 61.0 22.0 26.5 14.4 31.3 15 30 40 40 38.6
    20 25 RU-20-25 62.3 22.0 26.5 26.0 31.3 16 32 40 40 39.9



    (FRACTIONAL)

    TUBE O.D. CATALOG
    NUMBER    		 A C1 C2 D1 D2 E G1 G2 F H
    T1 T2
    1/8 1/4 RU-01-02 39.4 16.1 17.7 13.7 15.3 3 12 14 14 25.4
    1/4 5/16 RU-02-02 42.3 17.7 18.6 15.3 16.2 5 14 17 17 27.7
    1/4 3/8 RU-02-03 44.5 17.2 19.5 15.3 17.2 6 14 19 19 29.5
    1/4 1/2 RU-02-04 47 17.7 22.0 15.3 22.8 5 14 22 22 29.5
    5/16 3/8 RU-25-03 45.1 18.6 19.5 16.2 17.2 6 17 19 19 30
    5/16 3/8 RU-25-04 47.8 18.6 22.0 16.2 22.8 6 17 22 22 30.2
    3/8 1/2 RU-03-04 48.7 19.5 22.0 17.2 22.8 8 19 22 22 31.0
    1/2 3/4 RU-04-06 52.4 22.0 26.5 22.8 31.3 8 22 30 30 32.2
    3/4 1 RU-06-08 61.0 22.0 26.5 24.4 31.3 15 30 40 40 38.6
